Gira System 3000 DALI-2 vermogensregelingsmodule voor Tunable White 541100

This DALI-2 power control insert from Gira System 3000 enables precise dimming and colour temperature control of DALI DT8 Tunable White luminaires. It supports up to 10 DALI participants with a maximum DALI current of 20 mA and cable length up to 300 m.

Advantages

The insert offers a memory function and scene control capability when combined with a suitable Gira System 3000 top unit. Its flush-mounted design with an installation depth of 32 mm allows integration into standard wall boxes.

Suitable for

• Controlling DALI-2 Tunable White (DT8) LED luminaires
• Residential and commercial lighting applications
• Integration with Gira System 3000 control rockers

Key specifications

• Input voltage: AC 230 V, 50/60 Hz
• Standby power consumption: approx. 0.3 W
• DALI standard: DALI-2 (IEC 62386-101, -102, -207, -209)
• Connection: screw terminals, max. conductor cross-section 2.5 mm²
• Operating temperature: -5 °C to +45 °C

Recommendations

Pair with a Gira System 3000 top unit for full dimming and scene functionality.
