GRAFENTHAL Glasvezelkabel OM1, SC Duplex naar SC Duplex, 1m, Oranje, LSZH

The GRAFENTHAL Optical Fibre Cable OM1 is a high-quality duplex multimode patch cable designed for reliable data transmission in Gigabit Ethernet and Fibre Channel networks. With SC Duplex connectors on both ends and a 1-meter length, this cable is ideal for short-distance connections in data centers, ODFs, and enterprise environments.

Advantages

This OM1 cable features a 62.5/125 µm core/cladding, ensuring compatibility with legacy multimode systems. The LSZH (Low Smoke Zero Halogen) jacket provides enhanced safety in confined spaces, reducing toxic fumes and smoke in case of fire. The orange jacket color allows for easy identification and cable management.

Suitable for

• Gigabit Ethernet (1000BASE-SX)
• Fibre Channel (1/2 GFC)
• Optical Distribution Frames (ODF)
• Data center patching
• Short-distance backbone connections

Key specifications

• Fiber Type: OM1 Multimode (62.5/125 µm)
• Connectors: SC Duplex to SC Duplex
• Cable Length: 1 meter
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Color: Orange
• Insertion Loss: < 0.3 dB (typical)
• Return Loss: > 30 dB (typical)
• Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1300nm
• Bandwidth: 200 MHz·km @ 850nm, 500 MHz·km @ 1300nm
• Operating Temperature: -20°C to 70°C
• Minimum Bend Radius: 30 mm (dynamic), 10 mm (static)
• Cable Diameter: 3.0 mm
• Compliance: RoHS, CE

Recommendations

For optimal performance, ensure connectors are clean before installation. This cable is suitable for indoor use only. For longer distances, consider OM3 or OM4 fiber types.
