Hager TXE531 digitale tijdschakelaar, 1-kanaal, weekprogramma, DIN-rail, 230 V AC, 16 A, IP44

With a wide operating temperature range of -30 to 50 °C and IP44 protection, the Hager TXE531 digital time switch is built for challenging environments. This 1-channel weekly timer offers 56 memory locations and a 5-year power reserve, ensuring reliable switching even after long power outages.

Overview

The TXE531 is a DIN rail mountable digital time switch with a clear LCD display and manual override. It operates on 230 V AC at 50/60 Hz and can switch loads up to 16 A via its changeover contact. The device occupies 2 TE modules and consumes only 0.5 W.

What stands out

• Wide operating temperature range: -30 to 50 °C
• IP44 protection against dust and water splashes
• 56 program memory locations for flexible scheduling
• 5-year power reserve keeps time during outages
• Manual override for immediate control

Technical details

• Product type: Digital time switch
• Number of channels: 1
• Program type: Weekly
• Mounting: DIN rail
• Modules: 2 TE
• Supply voltage: 230 V AC
• Frequency: 50/60 Hz
• Switching capacity: 16 A (250 V AC, cos φ = 1)
• Contact type: 1 changeover (SPDT)
• Shortest switching time: 1 minute
• Display: LCD
• Power consumption: 0.5 W

Our verdict

The Hager TXE531 is a robust and versatile time switch for demanding applications, offering precise scheduling and dependable operation in harsh conditions.
