Hager Volta inbouw kleinverdeler, 3 rijen, 24 modules, grijs ABS, IP30 GB080317035

Electricians and installers working on residential, commercial, or light industrial projects will appreciate the Hager Volta small distribution board for flush-mounted installations. This 3-row enclosure provides 24 modules of space, making it suitable for organizing circuit breakers, residual current devices, and other modular devices in a compact footprint.

Key specifications

• Series: Volta
• Mounting type: Flush-mounted
• Number of rows: 3
• Modules per row: 8
• Total modules: 24
• Material: ABS plastic
• Colour: Grey (RAL 7035)
• Protection class: IP30
• Impact resistance: IK07
• Rated current: 63 A
• Glow wire test: 650 °C
• Halogen-free: Yes
• Door type: Steel door
• Door opening angle: 120°
• Installation depth: 90 mm
• Operating temperature: -5 to 40 °C
• Standards: DIN VDE 0603-1, DIN 43871
• Included components: N and PE terminals, DIN rails, cable entry slides

Why choose it

The steel door with 120° opening angle provides easy access during wiring and maintenance, while the ABS plastic enclosure is halogen-free and offers good impact resistance. The included N and PE terminals and DIN rails simplify installation, saving time on site.

Ideal use cases

• Residential electrical distribution
• Commercial building sub-distribution
• Light industrial control panels

Good to know

The board is designed for flush mounting and complies with DIN VDE 0603-1 and DIN 43871. It is rated for 63 A and suitable for operating temperatures from -5 to 40 °C.
