Hager VZ551N 3-fasen pen-verzamelrail 12 modules 280mm 63A

In distribution boards, connecting multiple modular devices with individual wires creates clutter, increases assembly time, and raises the risk of loose connections. The Hager VZ551N pin busbar solves this by providing a single, fully insulated copper bar that links up to 12 modules in one step.

Who is it for

Electricians and panel builders who install DIN rail devices in residential or commercial distribution boards and need a reliable, space-saving power distribution solution.

Main features

• 12-module pin busbar for 1-phase or 3-phase distribution
• Rated current 63 A, rated voltage 230/400 V AC
• Conductor cross-section 10 mm², copper material
• Pin type connections, fully insulated
• Length 280 mm, fits standard DIN rail devices
• Operating temperature -25 to +70 °C

Specifications

• Number of phases: 1-phase
• Number of modules: 12
• Conductor cross-section: 10 mm²
• Rated current: 63 A
• Rated voltage: 230/400 V AC
• Connection type: Pin type
• Insulation: Fully insulated
• Material: Copper
• Length: 280 mm
• Product colour: Grey
• Operating temperature: -25 to +70 °C

Tips

Ensure the busbar is compatible with the device terminal depth and phase assignment before installation. Use end caps to cover unused pin positions for safety.
