HAGER WDE2040 mechanische tijdschakelaar 2-polig 15 min inbouw

Controlling lighting or ventilation on a fixed 15-minute schedule without complex programming is a common need in residential and commercial settings. The HAGER WDE2040 mechanical timer switch offers a straightforward solution: a flush-mounted, 2-pole timer that activates connected loads for exactly 15 minutes after a push-button press.

Who is it for

This timer is ideal for electricians and installers working on stairwells, corridors, bathrooms, or utility rooms where a simple, reliable timed switching function is required. It suits users who prefer mechanical operation over digital programming and need a robust device for frequent switching.

Main features

• Mechanical timer with push-button activation and rotary setting
• Fixed switching time: 15 minutes
• 2-pole switching (2 NO contacts) for safe disconnection of both live conductors
• Flush-mounted (Unterputz) installation in standard wall boxes
• Rated current: 16 A resistive, 10 AX inductive (e.g., fluorescent loads)
• Operating voltage: 230 V AC, 50/60 Hz
• Compact design with installation depth of only 32 mm
• Durable thermoplastic housing in polar white (RAL 9010)

Specifications

• Timer type: Mechanical
• Mounting type: Flush-mounted (Unterputz)
• Number of poles: 2
• Switching function: Timer switch (push-button with rotary setting)
• Minimum switching time: 15 min
• Maximum switching time: 15 min
• Operating voltage: 230 V AC
• Rated current (resistive load): 16 A
• Rated current (inductive load): 10 AX
• Frequency: 50/60 Hz
• Contact type: 2 NO contacts
• Connection type: Screw terminals
• IP protection class: IP20
• Material: Thermoplastic
• Color: Polar White (RAL 9010)
• Installation depth: 32 mm
• Operating temperature: -5 to +40 °C
• Series: Hager we

Tips

For installations where a longer or adjustable time is needed, consider Hager's programmable timers. Always ensure the load does not exceed the rated current, especially for inductive loads like fluorescent lamps, which are limited to 10 AX.
