Hager WNC302 rolluik-serietaster, 2-kanaals, inbouw, polarwit

The Hager WNC302 stands out as a dedicated series push-button for controlling two independent roller shutters or blinds from a single flush-mounted insert. Unlike standard light switches, it provides momentary up/down/stop commands for each channel, making it the practical choice for coordinated facade control in residential and commercial installations.

Highlights

• Controls two roller shutters, blinds, awnings, or ventilation flaps independently
• Momentary contact switching principle for precise positioning
• Flush-mounted design with screw terminals for secure wiring
• Halogen-free thermoplastic housing in polar white
• Rated for 250 V AC / 10 A per channel

In daily use

Each of the two rockers gives you up, down, and stop control for its assigned drive. The WNC302 fits standard flush boxes with an installation depth of 32 mm and accepts rigid conductors from 1.5 to 2.5 mm². It is designed for use with a compatible central plate and frame, which are ordered separately to match your switch range.

Full specifications

• Product type: Roller shutter series push-button
• Number of operating elements: 2 (double push-button)
• Switching principle: Momentary contact
• Mounting type: Flush-mounted
• Connection type: Screw terminals
• Rated voltage: 250 V AC
• Rated current: 10 A
• Housing material: Thermoplastic
• Halogen-free: Yes
• Colour: Polar white
• Protection class: IP20
• Installation depth: 32 mm
• Terminal capacity: 1.5 - 2.5 mm² (rigid conductors)
• Operating temperature: -5 to +40 °C
• Switching contacts: 2-pole per channel

Final note

The WNC302 is a compact, halogen-free insert that brings reliable two-channel blind control to any flush-mounted installation, ready to be completed with your preferred cover plate and frame.
