HDMI 2.0-poortmodule ASUS PB63 (90MA0000-P00600) – HDMI 2.0-interface voor PB63

This HDMI 2.0 Port Module is a direct replacement part for the ASUS PB63 desktop or system described by the manufacturer code. The module provides a standard HDMI 2.0 interface on compatible PB63 units, restoring high-bandwidth digital video and multi-channel audio connectivity. It is designed for repair or upgrade of systems where the original HDMI connector is damaged, loose, or otherwise non-functional and is intended for installation by service technicians or users familiar with internal component replacement.

Advantages

The HDMI 2.0 module supports higher video bandwidth and up to 4K resolution at 60 Hz where system hardware and software allow, enabling improved display performance compared with older HDMI revisions. As an OEM-style replacement designed for the PB63, the module matches the physical fit and connector alignment of the original part, reducing the need for enclosure modification. The connector provides reliable digital audio and video transfer and is suitable for restoring full HDMI functionality after connector damage.

Suitable for

• Repairing an ASUS PB63 with a damaged or non-functioning HDMI port
• Replacing a worn or loose HDMI connector to restore reliable video/audio output
• Professional service and technician use during system maintenance or refurbishment

When it may not be suitable

This module is specific to ASUS PB63 systems and may not be compatible with other models or third-party enclosures. It does not include external cables, adapters, or tools required for installation, nor does it change the underlying video chipset capabilities of the host system. If the problem lies with the motherboard, GPU, firmware, or software settings rather than the HDMI connector itself, replacing the port module will not resolve the issue.

Key specifications

• Interface standard: HDMI 2.0 (supports increased bandwidth compared with HDMI 1.4)
• Supported output: Digital video and multi-channel audio (dependent on host hardware)
• Resolution capability: Up to 4K at 60 Hz when combined with compatible system hardware and cables
• Form factor: Replacement port module designed for ASUS PB63 internal mounting
• Intended use: Internal replacement for repair or refurbishment

How to use

Power down the PB63 system and disconnect all external power and peripherals before beginning. Open the chassis following the manufacturer's service instructions and locate the existing HDMI connector on the appropriate internal board. Carefully desolder or detach the faulty port module and install the replacement module, ensuring correct orientation and secure mechanical and electrical connections. Reassemble the chassis, reconnect power and peripherals, and verify HDMI output using a compatible display and cable. Installation should be performed by trained technicians or users experienced with electronic repairs to avoid damage to the system or the replacement part.

What to consider before purchase

• Confirm compatibility specifically with the ASUS PB63 model and the original port location
• Ensure you have the necessary tools and repair skills or access to professional service
• Check that the issue is limited to the HDMI connector and not the motherboard, GPU, or firmware
• Note that cables, adapters, and installation hardware are not included

Recommendations

Use a high-quality HDMI 2.0 cable and a display that supports the intended resolution and refresh rate. After installation, update system drivers and firmware if available, and test audio/video output across different resolutions to confirm stability.
