HEINRICH KOPP 562356009 2-polige wipschakelaar, 16 A, 250 V, rood/wit, snap-in

This 2-pole rocker switch from HEINRICH KOPP offers reliable ON-OFF control for a wide range of electrical applications. Its snap-in panel mounting and flat plug terminals ensure quick installation and secure connections.

Advantages

The switch features a robust polyamide housing and silver alloy contacts, providing long electrical life and high insulation resistance. The red actuator with white I/O markings is clearly visible and easy to operate.

Suitable for

• Control panels and electrical enclosures
• Industrial equipment and machinery
• Household appliances and lighting circuits

Key specifications

• Switch type: Rocker switch
• Number of poles: 2-pole (DPST)
• Switching function: ON-OFF (1-0)
• Rated voltage: 250 V AC
• Rated current: 16 A
• Connection type: Flat plug terminals (6.3 x 0.8 mm)
• Mounting type: Snap-in panel mount
• Mounting cutout: 30 x 22 mm
• Actuator colour: Red
• Markings: White I/O
• Illumination: No
• Electrical life: >10,000 cycles
• Insulation resistance: >100 MΩ (at 500 V DC)
• Dielectric strength: 1500 V AC (1 minute)
• Operating temperature: -20 to +85 °C
• Housing material: Polyamide (PA)
• Contact material: Silver alloy
• Certifications: VDE, ENEC

Recommendations

Ideal for applications requiring a durable, high-current switch with clear visual status indication.
