Heinrich Kopp centraalplaat antraciet 402615004

The Heinrich Kopp Central Plate in Anthracite (model 402615004) is a high-quality cover plate designed for switches, push-buttons, and sockets. Made from durable thermoplastic with a matt finish, it offers a modern and elegant look for any interior. This plate is halogen-free, UV-resistant, and impact-resistant, ensuring long-lasting performance. It is compatible with Kopp Standard and Kopp Paris series mechanisms and mounts via clip-on/snap-in for easy installation. The square design with visible dimensions of 55x55 mm and a depth of 11 mm makes it suitable for flush-mounted installations. Compliant with DIN 49075, this central plate provides reliable protection with IP20 rating.

Advantages

High-quality thermoplastic material ensures durability and resistance to chemicals and impacts. The matt anthracite finish adds a touch of sophistication to any room. Easy clip-on installation saves time during setup. Halogen-free construction makes it environmentally friendly and safe for use in sensitive areas.

Suitable for

• Residential and commercial electrical installations
• Use with Kopp Standard and Kopp Paris series switches, push-buttons, and sockets
• Flush-mounted applications requiring a sleek, square cover plate

Key specifications

• Product Type: Central Plate
• Colour: Anthracite
• Material: Thermoplastic
• Surface Finish: Matt
• Halogen-free: Yes
• Protection Class: IP20
• Mounting Type: Clip-on / Snap-in
• Design: Square
• Visible Width: 55 mm
• Visible Height: 55 mm
• Depth (visible): 11 mm
• Standard Compliance: DIN 49075
• UV-resistant: Yes
• Chemical Resistance: Yes
• Impact Resistance: Yes

Recommendations

For a complete installation, pair this central plate with a compatible frame (e.g., 1-gang or 2-gang frame) and the appropriate switch or socket insert. Ensure the underlying mechanism is flush-mounted for optimal fit.
