HEINRICH KOPP mechanische eenfasige wisselstroommeter 230V 5(30)A klasse 2 DIN-rail 4TE 192200011

Monitoring single-phase energy consumption in residential and light commercial installations requires a reliable meter that works without complex setup. The HEINRICH KOPP mechanical AC meter provides straightforward kWh measurement with a robust roller counter display, ensuring long-term readability even without power.

Who is it for

Electricians, facility managers, and homeowners who need a simple, durable solution for sub-metering or basic energy monitoring on a DIN rail. Ideal for installations where a pulse output or smart connectivity is not required.

Main features

• Mechanical roller counter with 6+1 digits (up to 999999.9 kWh)
• Single-phase 230 V AC, 50 Hz operation
• Base current 5 A, maximum current 30 A
• Accuracy class 2 for active energy measurement
• DIN rail mounting, 4 TE width
• Screw terminals for secure connection

Specifications

• Meter type: Mechanical AC meter
• Phase: Single-phase
• Nominal voltage: 230 V AC
• Nominal frequency: 50 Hz
• Base current (Ib): 5 A
• Maximum current (Imax): 30 A
• Accuracy class: Class 2
• Measurement function: Active energy (kWh)
• Display type: Mechanical roller counter
• Number of digits: 6 + 1 (999999.9 kWh)
• Mounting type: DIN rail
• Module width: 4 TE
• Operating temperature range: -25°C to +55°C
• Connection type: Screw terminals
• Tariff type: Single tariff

Tips

Ensure the meter is installed in a dry, enclosed distribution board to maintain IP20 protection. For accurate readings, avoid exceeding the maximum current of 30 A.
