HellermannTyton 435-01650 HelaCon Easy 5-polige push-in connector, zwart, 0,5-2,5mm², 24A, 450V, halogeenvrij

For installers who demand speed without sacrificing safety, the HellermannTyton 435-01650 HelaCon Easy connector eliminates screw terminals and twisting entirely. This 5-pole push-in wire connector accepts solid conductors from 0.5 to 2.5 mm² and stranded conductors from 1.5 to 2.5 mm², locking each wire with a tin-plated copper contact that resists vibration and thermal cycling. The transparent-free black polycarbonate housing is halogen-free and UL94 V-2 rated, making it suitable for distribution boxes, luminaires, and control cabinets where space is tight and reliability is non-negotiable.

Highlights

• Tool-free push-in termination: strip 11 mm, insert, done — reusable for solid conductors
• 5 poles in one compact body, rated 24 A / 450 V AC
• Halogen-free polycarbonate housing, UL94 V-2 flammability rating
• Accepts solid (0.5–2.5 mm²) and stranded (1.5–2.5 mm²) copper conductors
• VDE and ENEC approved, pollution degree 2, IP20

In daily use

Electricians often face junction boxes where traditional screw terminals are slow to wire and prone to loosening. The HelaCon Easy solves both problems: each pole has an independent spring-loaded clamp that maintains constant contact pressure, even under temperature swings from -30 °C to +85 °C. The 11 mm stripping length is clearly marked on the housing, reducing guesswork. Because the connector is reusable for solid conductors, you can reconfigure circuits without cutting and re-stripping wires — a real time-saver during testing or retrofits. The black housing blends into dark enclosures and resists marking, keeping installations looking professional.

Full specifications

• Brand: HellermannTyton
• Model: 435-01650 (HelaCon Easy series)
• MPN: 435-01650
• EAN: 4250596413777
• Number of poles: 5
• Connection type: Push-in
• Conductor type: Solid and stranded copper
• Wire cross-section solid: 0.5 – 2.5 mm²
• Wire cross-section stranded: 1.5 – 2.5 mm²
• Rated voltage: 450 V AC
• Rated current: 24 A
• Housing material: Polycarbonate (PC)
• Contact material: Copper, tin-plated
• Flammability rating: UL94 V-2
• Operating temperature range: -30 °C to +85 °C
• Stripping length: 11 mm
• Approvals: VDE, ENEC
• Reusability: Reusable for solid conductors
• Pollution degree: 2
• Protection class: IP20
• Halogen-free: Yes
• Product colour: Black

Final note

When code compliance and long-term stability matter, the 435-01650 delivers a maintenance-free connection that installs in seconds. Stock it for your next lighting or building automation project.
