HellermannTyton 712-00901 PVC elektro-isolatietape, zwart, 15 mm x 10 m, 0,15 mm dikte, rubberlijm

With a dielectric strength of 6 kV, this PVC tape delivers reliable insulation for low-voltage electrical work up to 1 kV. The rubber-based adhesive bonds firmly to cables and connectors, while the 0.15 mm thick PVC backing provides flexibility and resistance to abrasion.

Overview

The HellermannTyton 712-00901 is a black PVC electrical insulation tape supplied on a single roll. It measures 15 mm in width and 10 m in length, making it suitable for insulating, bundling, marking, protecting and repairing electrical connections. The tape is self-extinguishing and operates within a temperature range of -10 °C to +90 °C.

What stands out

• High dielectric strength of 6 kV for safe insulation on low-voltage circuits
• Rubber-based adhesive ensures strong adhesion to a variety of surfaces
• Self-extinguishing PVC backing enhances fire safety
• Wide operating temperature range from -10 °C to +90 °C
• Conforms to IEC 60454-3-1 Type 5 and VDE 0340 Part 3-1 Type 5 standards

Technical details

• Tape type: Electrical insulation tape
• Material: PVC (Polyvinyl Chloride)
• Adhesive type: Rubber-based
• Colour: Black
• Width: 15 mm
• Length: 10 m
• Thickness: 0.15 mm
• Dielectric strength: 6 kV
• Voltage rating: Up to 1 kV
• Tensile strength: 20 N/10 mm
• Elongation at break: 180%
• Operating temperature range: -10 °C to +90 °C
• Flame retardancy: Self-extinguishing
• Application: Electrical insulation, bundling, marking, protection, repair
• Standard compliance: IEC 60454-3-1 Type 5, VDE 0340 Part 3-1 Type 5
• Packaging: Single roll

Our verdict

A dependable PVC insulation tape for electricians and maintenance tasks, offering strong adhesion, good electrical insulation and self-extinguishing properties in a compact size.
