HELLERMANNTYTON HelaTape Power 750 zelfvulkaniserende isolatietape, 19 mm x 9,1 m, zwart 711-00300

With a dielectric strength exceeding 30 kV/mm, this self-fusing EPR tape delivers reliable primary electrical insulation for low- and medium-voltage applications up to 69 kV.

Overview

HELLERMANNTYTON HelaTape Power 750 is a self-amalgamating rubber tape made of ethylene propylene rubber (EPR). It fuses to itself without adhesive, forming a homogeneous, moisture-tight seal. The tape is black, 19 mm wide, 9.1 m long, and 0.76 mm thick. It operates from -40 °C to +90 °C and withstands short-term overloads up to +130 °C.

What stands out

• Self-fusing: no adhesive residue, bonds only to itself
• High elongation at break (>900%) for conformable wrapping
• Excellent UV and water resistance for outdoor use
• Meets ASTM D-4388 standard for insulating tape

Technical details

• Tape type: Self-amalgamating rubber tape
• Material: Ethylene Propylene Rubber (EPR)
• Colour: Black
• Width: 19 mm
• Length: 9.1 m
• Thickness: 0.76 mm
• Dielectric strength: > 30 kV/mm
• Operating temperature: -40 °C to +90 °C
• Short-term overload temperature: +130 °C
• Voltage rating: up to 69 kV
• Elongation at break: > 900%
• Tensile strength: > 1.0 MPa
• Water absorption: < 0.1%
• UV resistance: Good
• Application: Primary electrical insulation, moisture sealing, cable repair
• Adhesive type: Self-fusing (no adhesive layer)
• Standards: ASTM D-4388
• Packaging: Individual roll

Our verdict

A professional-grade self-fusing tape for demanding insulation and sealing tasks, offering high dielectric strength and broad temperature tolerance.
