HellermannTyton MB4A kabelbinderhouder - zwart - polyamide 6.6 - 44x24 mm - schroefbevestiging - 1 stuk

The HellermannTyton MB4A Cable Tie Mount is a robust and reliable solution for securing cable ties in various applications. Made from high-quality Polyamide 6.6 (PA66) in black, this mount offers excellent durability and temperature resistance. Designed for screw mounting with a fixing hole diameter of 4.3 mm (recommended screw M4), it provides a secure anchor point for cable ties up to 8.1 mm wide. With a base length of 44 mm and width of 24 mm, it is compact yet strong. Suitable for operating temperatures from -30 °C to +130 °C, it meets UL94 V2 flammability rating and is halogen-free and RoHS compliant. Ideal for cable routing and bundling in industrial, automotive, and electrical installations.

Advantages

High-quality Polyamide 6.6 material ensures long-lasting performance. Wide temperature range and UL94 V2 rating guarantee safety and reliability. Halogen-free and RoHS compliant for environmental responsibility. Easy screw mounting with standard M4 screws. Compact design saves space while providing secure cable tie fixation.

Suitable for

• Cable management in control cabinets and electrical panels
• Automotive wiring harnesses
• Industrial machinery and equipment
• Telecommunications and data centers
• General cable routing and bundling applications

Key specifications

• Product Type: Cable Tie Mount
• Series: MB4A
• Material: Polyamide 6.6 (PA66)
• Color: Black
• Mounting Method: Screw Mounting
• Fixing Hole Diameter: 4.3 mm
• Recommended Screw Size: M4
• Maximum Cable Tie Width: 8.1 mm
• Base Length: 44 mm
• Base Width: 24 mm
• Overall Height: 9.5 mm
• Operating Temperature Range: -30 °C to +130 °C
• Flammability Rating: UL94 V2
• Halogen-free: Yes
• UV Resistance: No
• RoHS Compliance: Yes
• Quantity per Unit: 1 Piece

Recommendations

For optimal performance, use with HellermannTyton cable ties of appropriate width. Ensure screw mounting is secure and the surface is clean and dry. Suitable for indoor and protected outdoor applications.
