Hermetische behuizing LN-BOX-DIN-IP65

The LN-BOX-DIN-IP65 is a robust, hermetic enclosure designed for demanding indoor and outdoor applications. Made from high-quality ABS plastic with an IP65 rating, it provides excellent protection against dust and water jets. The enclosure features a wall-mountable design with an included DIN rail for internal mounting, making it ideal for electrical and electronic installations.

Advantages

This enclosure offers superior durability and protection. Its IP65 rating ensures resistance to dust and water, while the IK07 impact rating protects against mechanical shocks. The UV-resistant ABS material and polyurethane gasket provide long-lasting performance in harsh environments. The opaque lid with 4 plastic screws ensures secure closure, and the smooth walls allow for custom cable entry drilling.

Suitable for

• Electrical distribution boxes
• Control and automation systems
• Telecommunications equipment
• Industrial and outdoor installations

Key specifications

• Ingress Protection: IP65
• Impact Protection: IK07
• Material: ABS Plastic
• Color: Light Grey (RAL 7035)
• Mounting: Wall mountable with included DIN rail
• Lid: Opaque with 4 plastic screws
• Seal: Polyurethane gasket
• Operating Temperature: -25°C to +60°C
• UV Resistant: Yes
• Chemical Resistance: Good (weak acids, alkalis, oils, fats)
• Flammability: Self-extinguishing
• Standards: CE, RoHS

Recommendations

For optimal installation, ensure proper cable entry sealing to maintain IP65 protection. Suitable for both indoor and outdoor use, this enclosure is a reliable choice for protecting sensitive electronic components.
