Hikvision DS-220AZJ-130-WA AC/DC-voeding 12V 1A EU-stekker

The Hikvision DS-220AZJ-130-WA is a high-quality AC/DC power adapter designed to provide reliable power to Hikvision CCTV cameras, DVRs, NVRs, and other compatible 12V DC devices. With a compact design and EU wall plug, this adapter ensures stable performance and safety for your surveillance equipment.

Advantages

This power adapter offers efficient power conversion with an efficiency level of VI, reducing energy waste. It includes comprehensive protection features such as over-voltage, over-current, and short-circuit protection, safeguarding your connected devices. The 1.2-meter cable provides flexibility in placement, and the center-positive barrel connector ensures compatibility with a wide range of Hikvision products.

Suitable for

• Hikvision CCTV cameras
• Hikvision DVRs and NVRs
• Other 12V DC devices with 5.5mm x 2.1mm barrel plug

Key specifications

• Product Type: AC/DC Power Adapter
• Input Voltage: 100-240V AC
• Input Frequency: 50/60 Hz
• Output Voltage: 12V DC
• Output Current: 1A
• Output Power: 12W
• DC Connector: 5.5mm x 2.1mm Barrel Plug, Center Positive
• AC Plug Type: EU Wall Plug
• Cable Length: 1.2 meters
• Efficiency Level: VI
• Protection: Over-voltage, Over-current, Short-circuit
• Operating Temperature: -10°C to 40°C
• Certifications: CE, FCC, RoHS

Recommendations

For optimal performance, use only with compatible Hikvision devices. Ensure the adapter is plugged into a stable power source and avoid exposure to extreme temperatures or moisture.
