HIKVSION DS-2FP2061 indoor omnidirectionele condensatormicrofoon voor Hikvision DVR/NVR

The HIKVSION DS-2FP2061 is a high-performance indoor omnidirectional condenser microphone designed for seamless integration with Hikvision DVRs, NVRs, and other audio input devices. It delivers clear audio pickup over an area of 5 to 100 m², making it ideal for security surveillance, conference rooms, and office environments.

Advantages

• Omnidirectional pickup captures sound from all directions, ensuring no audio死角.
• Wide frequency response (100 Hz – 10 kHz) provides natural voice reproduction.
• High sensitivity (-30 dB) and SNR (58 dB) for clear audio even in noisy environments.
• Easy installation on walls or ceilings with integrated 0.5 m cable.
• Compatible with Hikvision recording equipment and other standard audio inputs.

Suitable for

• Security surveillance systems requiring audio monitoring
• Conference rooms and meeting spaces
• Office intercom and communication setups
• Retail stores, banks, and public facilities

Key specifications

• Microphone Type: Omnidirectional Condenser
• Audio Pickup Area: 5 to 100 m²
• Frequency Response: 100 Hz – 10 kHz
• Sensitivity: -30 dB
• Signal-to-Noise Ratio: 58 dB
• Output Impedance: 600 Ω (unbalanced)
• Audio Output Interface: RCA
• Power Supply: DC 12V
• Power Consumption: Max. 100 mA
• Integrated Cable Length: 0.5 m
• Housing Material: PVC
• Operating Temperature: -25°C to 70°C
• Operating Humidity: 10% – 90% (non-condensing)
• Installation: Wall/Ceiling Mountable
• Application Environment: Indoor

Recommendations

For optimal performance, connect the microphone to a compatible Hikvision DVR or NVR using the RCA audio input. Ensure the power supply is stable DC 12V. The microphone is designed for indoor use only; avoid exposure to moisture or extreme temperatures.
