Canon 28 tands tandwiel

Precision-engineered for Canon imaging devices, this 28-tooth spur gear restores reliable paper feed and fuser operation without the cost of a full assembly. Its high-strength POM construction and exact tooth profile make it a direct, durable replacement for worn OEM gears.

Highlights

• 28 teeth, module 1.0M, 20° pressure angle for smooth meshing
• High-strength engineering plastic (POM/acetal) resists abrasion and impact
• Round 4 mm bore and 8 mm face width for a direct fit
• White colour matches many original Canon gears
• Operating range -20°C to 80°C, ISO 9001 production

In daily use

Installation is straightforward: remove the old gear, press this replacement onto the shaft, and reassemble. The gear's precise dimensions ensure consistent torque transfer, reducing jams and extending the life of your printer or copier. Suitable for paper feed and fuser drive mechanisms.

Full specifications

• Type: Spur gear
• Number of teeth: 28
• Module: 1.0M
• Pressure angle: 20°
• Outer diameter: approx. 30 mm
• Bore diameter: 4 mm (round)
• Face width: 8 mm
• Material: POM/acetal engineering plastic
• Colour: White
• Application: Canon printer/copier paper feed, fuser unit
• Operating temperature: -20°C to 80°C
• Resistance: Abrasion, impact, chemical
• Manufacturing standard: ISO 9001

Final note

Restore dependable paper handling with this precision Canon gear — a cost-effective fix for common drive failures.
