HP Drive-Feed X7600 K7600

High-volume technical printing often forces a choice between speed and quality, but the HP PageWide XL K7600 eliminates that compromise. This drive-feed production printer delivers monochrome and color A1/D prints at up to 20 pages per minute, making it ideal for architecture, engineering, and construction teams that need fast turnaround without sacrificing fine detail.

Who is it for

Designed for reprographic departments, large design firms, and print service providers, the K7600 handles demanding workloads with ease. Its six-roll capacity and automatic switching keep long jobs running uninterrupted, while the integrated top stacker organizes up to 500 pages for efficient finishing.

Main features

• HP PageWide XL Technology with 8 fixed printheads for consistent, high-speed output
• Up to 20 D/A1 pages per minute (1000 pages per hour)
• 1200 x 1200 dpi resolution for crisp lines and fine text
• Pigment-based CMYK inks for durable, water-resistant prints
• Six front-loading media rolls with auto-switching for continuous printing
• Supports media up to 40 inches wide and 0.4 mm thick
• Gigabit Ethernet and USB 2.0 host connectivity for flexible integration
• 16 GB DDR4 memory and 500 GB self-encrypting hard drive for fast processing and secure storage
• 15.6-inch touchscreen for intuitive control and job management
• Robust security with HP Secure Boot, whitelisting, and role-based access control

Specifications

• Print technology: HP PageWide XL
• Print speed: Up to 20 pages/min (D/A1)
• Print resolution: Up to 1200 x 1200 dpi
• Ink type: Pigment-based HP PageWide XL Inks (CMYK)
• Number of printheads: 8
• Media capacity: Up to 6 rolls, front-loading, auto-switching
• Maximum media width: 40 inches (101.6 cm)
• Maximum roll diameter: 7 inches (17.7 cm)
• Media thickness: Up to 0.4 mm (15.7 mil)
• Connectivity: Gigabit Ethernet (1000Base-T), USB 2.0 host
• Memory: 16 GB DDR4
• Hard drive: 500 GB self-encrypting (AES-256)
• Display: 15.6-inch touchscreen
• Power consumption (printing): 1.2 kW
• Printer languages: HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4, NIRS, 3MF, URF
• Security: HP Secure Boot, whitelisting, role-based access control, SNMPv3, HTTPS, IPsec, 802.1X, TLS
• Output stacker capacity: Up to 500 pages

Tips

To maximize throughput, load different media types across the six rolls and let the printer auto-switch based on job requirements. For secure environments, enable HP Secure Boot and role-based access control to protect sensitive documents and device settings.
