SFP Fibre Channel-module HP 16Gb Short-Wave voor SAN-connectiviteit

The HP SFP Fibre Channel module 16Gb short-wave is a hot-pluggable SFP transceiver designed for Fibre Channel storage area networks (SAN). It supports 16Gb/s short‑wave optical links and is intended for use with compatible HP switches and Host Bus Adapters (HBAs) to deliver high‑speed serial Fibre Channel connectivity between servers, storage arrays and switches in data center and enterprise storage environments.

Advantages

This module delivers 16Gb/s line rate performance in a compact SFP package, enabling higher throughput for SAN links while preserving port density on switches and HBAs. Hot‑pluggable design simplifies installation and replacement without powering down connected equipment. The short‑wave optical operation supports typical multimode fibre runs found in rack‑to‑rack and switch‑to‑switch connections, and the form factor is compatible with standard Fibre Channel management and diagnostics for interoperability and monitoring.

Suitable for

• Server-to-storage connections in enterprise SANs
• Switch-to-switch interconnects inside data centers
• SAN expansion and port upgrades on compatible HP infrastructure
• High-bandwidth storage replication and backup links

Key specifications

• Interface: Small Form-factor Pluggable (SFP) transceiver
• Protocol: Fibre Channel serial communication
• Data rate: 16 Gigabits per second (line rate)
• Optical type: Short‑wave (suitable for multimode fibre runs)
• Form factor: Hot‑pluggable for field replacement
• Typical applications: SAN links, switch uplinks, server HBAs

How to use

Install the SFP module into a compatible SFP port on an HP switch or HBA until it seats securely, following the host equipment’s insertion procedure. Connect appropriate multimode fibre patch cables to the module’s duplex optical ports, respecting transmit/receive orientation. After physical installation, confirm link establishment and verify speed and status through the switch or HBA management interface. Replace or relocate the module while the system is running if required, as the hot‑pluggable design supports live swapping.

Recommendations

Use multimode fibre and connectors that match the short‑wave optical specification and maintain proper fibre cleanliness to ensure signal integrity. Verify vendor compatibility with the host switch or HBA model and monitor link status and error counters during deployment to confirm optimal performance.
