Intel Xeon W9-3495X processor 1,9 GHz 56 cores 112 threads LGA 4677 tray

The Intel Xeon W9-3495X is a high-performance workstation processor designed for demanding professional workloads. With 56 cores and 112 threads, it delivers exceptional multi-threaded performance for tasks such as 3D rendering, video editing, scientific simulations, and AI development. Built on the Intel 7 (10nm) lithography, this processor offers a base clock speed of 1.9 GHz and a max turbo frequency of 4.8 GHz, ensuring fast and responsive computing. The large 105 MB Intel Smart Cache reduces latency and improves data access efficiency. Supporting up to 4 TB of DDR5 ECC RDIMM memory across 8 channels, it provides ample bandwidth for memory-intensive applications. With 112 PCI Express 5.0 lanes, it enables extensive expansion capabilities for multiple GPUs, NVMe SSDs, and other high-speed devices. The processor is unlocked for overclocking, allowing enthusiasts to push performance further. It also includes Intel vPro Platform Eligibility for enhanced manageability and security features. This tray version is intended for system integrators and OEMs.

Advantages

Unmatched multi-core performance for professional applications. Large cache and high memory bandwidth reduce bottlenecks. Extensive PCIe lanes support multiple high-end components. Overclocking capability for additional performance tuning. Intel vPro for remote management and security.

Suitable for

• Content creators and video editors working with 8K footage
• 3D artists and animators using complex rendering software
• Engineers and scientists running simulations and data analysis
• AI and machine learning developers training large models
• Workstation enthusiasts seeking top-tier performance

Key specifications

• Processor Family: Intel Xeon W
• Processor Model: W9-3495X
• Total Cores: 56
• Total Threads: 112
• Base Clock Speed: 1.9 GHz
• Max Turbo Frequency: 4.8 GHz
• Intel Smart Cache: 105 MB
• Thermal Design Power (TDP): 350 W
• Processor Socket: FCLGA4677
• Max Memory Size: 4 TB
• Memory Types: DDR5 ECC RDIMM
• Max Memory Speed: 4800 MHz
• Memory Channels: 8
• PCI Express Lanes: 112
• PCI Express Revision: 5.0
• Lithography: Intel 7 (10nm)
• Unlocked for Overclocking: Yes
• Integrated Graphics: No
• Intel vPro Platform Eligibility: Yes
• Instruction Set Extensions: Intel AVX-512, Intel AMX, Intel DL Boost

Recommendations

For optimal performance, pair this processor with a high-end workstation motherboard based on the Intel W790 chipset, ample DDR5 ECC memory, and a robust cooling solution capable of handling 350W TDP. Consider using multiple high-end GPUs for accelerated rendering or AI workloads.
