JUNG 8012W mechanische draaischakelaar tijdschakelaar inzet, 120 min, 16A, 250V, wit

The JUNG 8012W is a mechanical rotary timer switch insert that provides reliable time-controlled switching for lighting and other electrical loads. With a maximum setting of 120 minutes and a 16 A switching capacity, it is an ideal solution for countdown applications in residential and commercial environments.

Advantages

This timer insert features a robust mechanical rotary mechanism that requires no power supply for timing, ensuring consistent operation even during power interruptions. Its flush-mounted design integrates seamlessly with standard JUNG frames and covers from the AS, A, CD, and LS series, offering flexibility in design. The high switching capacity supports incandescent and halogen loads up to 2300 W, making it suitable for a wide range of lighting systems.

Suitable for

• Bathroom fans and ventilation systems
• Staircase lighting with automatic shut-off
• Heating and circulation pumps
• Outdoor lighting with timed activation
• Any application requiring a simple countdown timer

Key specifications

• Timer type: Mechanical rotary countdown timer
• Maximum switching time: 120 minutes
• Rated voltage: 250 V AC, 50/60 Hz
• Rated current: 16 A
• Contact configuration: 1 normally open (NO)
• Switching capacity: 2300 W incandescent/halogen, 1200 VA fluorescent
• Mounting: Flush-mounted (Unterputz)
• Protection class: IP20
• Color: White (Alpinweiß)
• Material: Thermoplastic
• Connection: Screw terminals
• Ambient temperature: 0 to +40 °C

Recommendations

For a complete installation, combine the 8012W with a compatible JUNG cover plate and frame from the AS, A, CD, or LS series. Ensure the load does not exceed the specified switching capacity to maintain reliable operation.
