Kabelverbinder EFB Elektronik 28606.1 – D-Sub 15-polig, vertind, grijs

EFB Elektronik 28606.1 is a wire connector for 15-pin D-sub interfaces, supplied as a single unit. The connector features a tin-plated housing with a grey finish and is intended for standard D-sub 15 signal and data cabling where a compact, plated female/male connection is required. The design supports reliable mating over multiple cycles and is suitable for installations that require a durable, low-corrosion plated contact surface.

Advantages

The tin-plated housing provides corrosion resistance and stable contact performance for signal transmission. The compact D-sub 15 form factor allows easy integration into equipment panels and cable assemblies. Rated at quality level III, the connector supports a high number of mating cycles (≥ 50), delivering consistent mechanical and electrical performance over time.

Suitable for

• Signal and data cabling for analog or digital devices
• Panel-mounted D-sub connections in industrial and instrumentation equipment
• Custom cable assemblies and repair of D-sub 15 interfaces
• Low-corrosion environments where tin plating is preferred

Key specifications

• Connector type: D-sub 15-pin
• Housing finish: tin-plated, grey
• Quantity: single unit per pack
• Durability: quality level III, ≥ 50 mating cycles
• Application: signal and data connections

How to use

Prepare cable conductors according to the D-sub 15 wiring scheme required for your application and insert wires into the connector contacts following the manufacturer's wiring conventions. Mount the connector to the panel or cable assembly using the appropriate screws or fastening hardware, ensuring secure mechanical connection and correct pin alignment. Verify continuity and correct pin mapping with a multimeter before final installation into the system.

Recommendations

For reliable long-term operation, avoid exposing the tin-plated connector to aggressive chemicals or prolonged high-humidity conditions. Perform periodic inspections of mating faces and fastening hardware, and confirm secure seating after repeated reconnections to maintain consistent signal quality.
