Keystone-module Tecline 272850 plat zwart RJ-45

The Tecline 272850 Flat Black RJ-45 keystone module is an unshielded category 5e connector designed for both solid and stranded network cables. Its flat black housing and compact dimensions (27 mm width, 18 mm depth, 22 mm height) make it suitable for modular faceplates and patch panels where space is limited. The module is sold individually and provides a standard RJ-45 interface for Ethernet installations.

Advantages

The module supports Cat5e wiring for typical Ethernet speeds and accepts both solid and stranded conductors, simplifying inventory and installation. Its flat profile allows installation in tight mounting spaces and a black finish provides a discreet appearance in matching faceplates or panels. The keystone format ensures compatibility with common modular mounting systems.

Suitable for

Key specifications

How to use

Terminate the network cable to the keystone module following the standard Cat5e wiring scheme (T568A or T568B) and insert conductors into the IDC or punch-down contacts according to the module’s marking. Snap the keystone into a compatible faceplate or patch panel opening until it locks. Connect an RJ-45 patch cable to the module to complete the link. Ensure proper cable management and strain relief to maintain connection reliability.

Recommendations

Use with Cat5e-rated solid or stranded cable and compatible keystone wall plates or patch panels. Choose the same wiring standard on both ends of the link (T568A or T568B). Avoid exceeding the intended environmental conditions for unshielded components; use shielded modules and cabling where additional EMI protection is required.
