KONTAK-SIMON Simon 54 Premium TV/R/SAT aansluitdoos, wit (DAK1.01/11)

Unlike basic antenna outlets that simply pass through a single signal, the Simon 54 Premium terminal socket from KONTAK-SIMON terminates a star-wired multimedia network with three dedicated outputs: TV, Radio, and Satellite. This flush-mounted module in pure white (RAL 9003) is engineered for residential and commercial installations where clean signal separation and low insertion loss are non-negotiable. The screw-terminal connections and compatibility with standard Simon 54 frames make it a straightforward upgrade for electricians and DIY enthusiasts alike.

Highlights

• Three independent outputs: IEC male for TV, IEC female for Radio, F-type female for Satellite
• Wide frequency coverage: 5–862 MHz for terrestrial TV/Radio, 950–2400 MHz for SAT
• Low insertion loss: <1.5 dB for TV/Radio, <2.0 dB for SAT
• DC pass for satellite (max 500 mA) to power LNBs or multiswitches
• Class A shielding effectiveness and >20 dB isolation between outputs
• High-quality thermoplastic (PC/ABS) housing, IP20 rated

In daily use

Installation is quick: the module snaps into any Simon 54 Premium frame (not included) over a standard flush-mounting box. Connect the incoming coaxial cables to the clearly marked screw terminals, then secure the front plate. The white finish blends with most interiors, and the robust construction withstands repeated plugging and unplugging. Whether you're setting up a living room media wall or a multi-room distribution system, this terminal socket ensures stable signal delivery without interference between bands.

Full specifications

• Series: Simon 54 Premium
• Socket type: TV/R/SAT terminal (end) socket
• Colour: White (RAL 9003)
• Number of outputs: 3 (TV, Radio, Satellite)
• TV frequency range: 5–862 MHz
• Radio frequency range: 5–862 MHz
• SAT frequency range: 950–2400 MHz
• TV insertion loss: <1.5 dB
• Radio insertion loss: <1.5 dB
• SAT insertion loss: <2.0 dB
• Impedance: 75 Ohm
• DC pass for SAT: Yes (max 500 mA)
• Shielding effectiveness: Class A
• Isolation between outputs: >20 dB
• Connection type: Screw terminals
• Mounting type: Flush mounting
• Material: High-quality thermoplastic (PC/ABS)
• Protection rating: IP20
• Compatibility: Simon 54 Premium frames and mounting boxes
• Output connector types: IEC male (TV), IEC female (Radio), F-type female (SAT)

Final note

For a reliable, low-loss termination point in any antenna distribution system, the DAK1.01/11 delivers professional-grade performance in a discreet, easy-to-install package.
