Lanview LVR-3MUK-SPD-UK10 stroomverdeleenheid (PDU) 8 AC-uitgangscontactdozen 1,4HE zwart

The Lanview LVR-3MUK-SPD-UK10 is a compact 1.4U rack-mounted power distribution unit (PDU) designed for server rooms and data centers. It provides eight grounded UK AC outlets and comes with a 5 metre power cable, supporting single-phase applications with a nominal input voltage of 250 V and a maximum current of 13 A. The black finish and slim 1.4U form factor make it suitable for organised equipment installations in rack cabinets.

Advantages

This PDU offers a compact 1.4U size that saves rack space while delivering eight UK AC outlets for multiple devices. The 5 m cable provides flexibility in cabinet placement, and the 13 A maximum current and 250 V nominal voltage match common single-phase server-room requirements. Constructed in black, it integrates visually into standard rack environments.

Suitable for

• Small to medium server rooms
• Data centre racks requiring basic power distribution
• Network cabinets with UK-plug equipment
• Single-phase IT and telecom installations

Key specifications

• AC outlets quantity: 8 AC outlet(s) (grounded UK sockets)
• Nominal input voltage: 250 V
• Maximum current: 13 A
• PDU type: Basic
• Rack size: 1.4U
• Cable length: 5 m
• Colour: Black
• Weight: 1.4 kg

How to use

Mount the Lanview LVR-3MUK-SPD-UK10 into a compatible 1.4U space in a rack cabinet using appropriate screws and mounting brackets. Connect the 5 m mains cable to a properly rated single-phase supply (250 V) and ensure the supply does not exceed 13 A in total for connected equipment. Plug devices with UK plugs into the grounded outlets and route cables to avoid obstruction of airflow inside the cabinet.

Recommendations

Do not exceed the rated maximum current of 13 A. Use the PDU in well-ventilated rack cabinets and connect it to a protected power source with proper grounding. Regularly inspect the cable and outlets for damage and avoid overloading individual outlets or the entire unit.
