LAPP dubbele adereindhuls, 0,75 mm², 8 mm, deels geïsoleerd, grijs, 500 stuks 61802000

Precision-engineered twin wire end sleeve with a 0.75 mm² cross-section and 8 mm crimp barrel, designed for reliable termination of fine-stranded conductors. The tin-plated electrolytic copper ferrule and grey polypropylene insulation ensure lasting performance in demanding applications.

Overview

This LAPP twin wire end sleeve (ferrule) is partially insulated, featuring a grey polypropylene collar that provides electrical insulation and strain relief. The ferrule is manufactured from electrolytic copper with a tin-plated surface for excellent conductivity and corrosion resistance. It accommodates two conductors with a total cross-section of 0.75 mm² and has a crimp barrel length of 8 mm. The insulation is rated for temperatures from -40°C to +105°C and meets UL 94 V-0 flammability standards. The product complies with DIN 46228 Part 4 and is RoHS compliant. Supplied in a pack of 500 pieces.

What stands out

• Tin-plated electrolytic copper ferrule for superior conductivity and corrosion resistance
• Grey polypropylene insulation rated for -40°C to +105°C
• Partially insulated design for secure crimping and strain relief
• Complies with DIN 46228 Part 4 and RoHS
• Pack of 500 pieces for high-volume applications

Technical details

• Nominal cross-section: 0.75 mm²
• Crimp barrel length: 8 mm
• Total length: 14.5 mm
• Insulation outer diameter: 3.0 mm
• Ferrule internal diameter: 1.3 mm
• Insulation material: Polypropylene (PP)
• Ferrule material: Electrolytic copper, tin-plated
• Insulation colour: Grey
• Temperature range: -40°C to +105°C
• Flammability rating: UL 94 V-0
• Number of conductors: 2
• Packaging quantity: 500 pieces

Our verdict

A dependable twin wire end sleeve for professional electrical installations, offering consistent performance and compliance with industry standards.
