Lenovo M.2-SSD-adapter – high-profile interfacekaarten/-adapters intern

The Lenovo M.2 SSD Adapter (4XH0L08578) is a full-height expansion card designed to install an M.2 SSD into ThinkStation systems with a high profile bracket. It provides a PCIe host interface and an M.2 output interface, enabling integration of M.2 storage into compatible Lenovo workstations. The adapter measures 121 mm (width) × 124 mm (depth) × 18.5 mm (height) and is internally mounted; the product colour is green.

Advantages

This adapter supports PCIe host connectivity and a standard M.2 output, allowing straightforward addition of M.2 SSDs to ThinkStation systems that accept full-height cards. Its compact dimensions and internal mounting make it suitable for workstation interiors, and the part is fully qualified for specified ThinkStation models.

Suitable for

• Installing an M.2 SSD in ThinkStation systems with a high profile/full-height expansion slot
• Upgrading internal storage on Lenovo workstations
• Systems requiring a PCIe-to-M.2 adapter for faster NVMe or SATA M.2 drives (dependant on SSD type)

Key specifications

• Manufacturer: Lenovo
• Model / MPN: 4XH0L08578
• Host interface: PCIe
• Output interface: M.2
• Form factor: Full-height expansion card
• Dimensions: 121 mm (W) × 124 mm (D) × 18.5 mm (H)
• Internal: Yes
• Weight: 0.03 kg
• Colour: Green
• EAN: 190151891906

How to use

Power down and unplug the ThinkStation before installation. Remove the workstation cover and locate a free full-height expansion slot. Insert the adapter into an available PCIe slot and secure it to the chassis using the existing bracket screws. Mount the M.2 SSD into the adapter following the SSD manufacturer’s instructions, ensuring the module is fully seated and fastened. Replace the cover, reconnect power, and verify the system BIOS/UEFI recognises the new drive; install any necessary drivers or initialise the disk within the operating system.

Recommendations

Confirm compatibility with your specific ThinkStation model and the M.2 SSD type (NVMe or SATA) before purchase. Follow anti-static precautions during installation and consult Lenovo support documentation for model-specific installation notes.
