LogiLink Cat.6A Premium patchkabel-verlenging, S/FTP, zwart, 3 m

For high-density 10-Gigabit networks where interference is the enemy, this LogiLink Cat.6A premium patch cable extension delivers the shielding and headroom that ordinary Cat.6 cables cannot. The S/FTP construction with individually foil-wrapped pairs and an overall braid keeps alien crosstalk at bay, while the LSZH jacket makes it safe for enclosed spaces.

Highlights

• Category 6A performance: supports 10GBASE-T up to 500 MHz bandwidth
• S/FTP shielding: each pair foil-screened plus overall braid for maximum noise immunity
• 100% copper conductors, 26 AWG stranded for flexibility without signal loss
• Gold-plated RJ45 connectors (50 µm) ensure reliable, corrosion-resistant contacts
• LSZH (Low Smoke Zero Halogen) jacket: low smoke and non-toxic in case of fire
• 3 m length ideal for patch panels, wall outlets, and device connections

In daily use

This cable is built for demanding environments: server rooms, data centers, and offices with dense cabling. The robust S/FTP shielding prevents electromagnetic interference from adjacent cables and equipment, maintaining full 10 Gbps throughput even in bundles. The stranded copper conductors make the cable flexible and easy to route, while the snagless boot design protects the locking tab during frequent reconnections. The black LSZH jacket is durable, yet remains pliable, and meets strict fire safety regulations for public buildings.

Full specifications

• Cable standard: Category 6A (Cat.6A)
• Shielding type: S/FTP (Screened Foiled Twisted Pair), PIMF
• Length: 3 m
• Colour: Black
• Connector type: RJ45 male to RJ45 male
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Data transfer rate: up to 10 Gbps (10GBASE-T)
• Bandwidth: up to 500 MHz
• Conductor material: 100% copper
• Conductor gauge: 26 AWG
• Wiring scheme: TIA/EIA 568B
• Connector plating: Gold (50 µm)
• Cable construction: Stranded
• Halogen free: Yes
• Flame retardant: Yes
• Outer diameter: approx. 6.2 mm
• Number of pairs: 4
• Compliance: RoHS, REACH, ISO/IEC 11801, EN 50173

Final note

When your network demands certified Cat.6A performance and safety, this LogiLink patch cable extension is the professional choice for reliable, high-speed connectivity.
