MACKIE 5,25 inch compact actief PA-systeem

With 150W of peak Class D power and a max SPL of 120 dB, this compact PA system delivers surprising punch from a 5.25-inch woofer. It's a three-channel powered speaker that doubles as a mini mixer, ready for small gigs, presentations, and rehearsals.

Overview

The MACKIE 5.25in. Compact Powered PA System is a self-contained sound reinforcement solution. It combines a powered full-range loudspeaker with a built-in 3-channel mixer, eliminating the need for external amplification or a separate mixing console. The high-impact polypropylene enclosure houses a 5.25-inch LF driver and a high-frequency driver, driven by efficient Class D amplification. Two combo XLR/TRS inputs accept microphones, line-level sources, or instruments, while a stereo RCA input accommodates consumer devices. Each of the first two channels features a 3-band active EQ for tone shaping, and phantom power is available for condenser microphones. The speaker can be mounted on a standard mic stand via the built-in mount, making placement flexible.

What stands out

• 150W peak Class D power with 120 dB max SPL for clear, loud output
• Built-in 3-channel mixer with two combo XLR/TRS inputs and stereo RCA
• 3-band active EQ on channels 1 and 2 for precise tonal control
• Phantom power support for condenser microphones
• Integrated mic stand mount for easy elevation and positioning
• Durable high-impact polypropylene enclosure with protection circuitry

Technical details

• Speaker type: Powered full-range loudspeaker
• LF driver size: 5.25 inches
• Amplifier type: Class D
• Power output (peak): 150 W
• Frequency response (-3 dB): 100 Hz – 17.5 kHz
• Max SPL: 120 dB @ 1 meter
• Mixer channels: 3
• Inputs: 2 x XLR/TRS combo, 1 x stereo RCA
• Outputs: 1 x XLR thru, 1 x 1/4" TRS monitor out
• EQ: 3-band active on channels 1 & 2
• Phantom power: Yes (channels 1 & 2)
• Input impedance (mic): 2.5 kΩ balanced
• Input impedance (line): 20 kΩ balanced
• Input impedance (instrument): 1 MΩ unbalanced
• Mounting options: Built-in mic stand mount
• Enclosure material: High-impact polypropylene
• Protection circuitry: Over-temperature, over-current, short-circuit
• Power supply: AC 100-240V, 50/60Hz

Our verdict

The MACKIE 5.25in. Compact Powered PA System is a versatile and portable sound solution for musicians, presenters, and event hosts. Its integrated mixer and powerful amplification make it a practical all-in-one choice for small venues and mobile setups.
