MEAN WELL DPBW03G-15 DC-DC-converter, 3W, 15V 200mA, 9-18V ingang, DIP24, geïsoleerd

Embedded systems engineers often face the challenge of deriving a stable 15V rail from a fluctuating 9–18V DC bus. The MEAN WELL DPBW03G-15 solves this with a compact, isolated 3W DC-DC converter that fits directly onto a DIP24 PCB footprint. Its 2:1 wide input range accommodates battery-powered or industrial intermediate bus voltages, while the 1500VDC isolation protects sensitive logic from ground loops and transients.

Key specifications

• Output: 15VDC, 200mA, 3W maximum
• Input: 9–18VDC (2:1 wide range)
• Isolation: 1500VDC input-to-output
• Efficiency: up to 85%
• Ripple & noise: 100mVp-p max
• Line/load regulation: ±0.5% max
• Protection: short circuit (SCP), overload (OLP)
• Operating temperature: -40°C to +85°C
• Switching frequency: 300kHz typical
• MTBF: >1,000,000 hours
• Mounting: DIP24, PCB through-hole

Why choose it

This converter delivers reliable, regulated power in harsh environments without external components. Its wide temperature range and built-in protections make it ideal for industrial control, telemetry, and battery-operated equipment where space is limited and reliability is non-negotiable.

Ideal use cases

• Industrial sensors and transmitters
• Battery-powered portable instruments
• Distributed power architectures
• Isolated gate drivers and communication nodes
• Automotive and transportation electronics

Good to know

The DPBW03G-15 is part of the DPBW03 series, known for its high power density and robust design. It is RoHS compliant and suitable for automated PCB assembly. No heatsinking is required under normal load conditions due to high efficiency and low thermal resistance.
