MEAN WELL OWA-60E-36 60W 36V AC/DC gesloten voeding IP67

Outdoor LED installations, industrial sensors, and automation systems often need reliable DC power in harsh environments. The MEAN WELL OWA-60E-36 delivers 36 VDC at up to 1.67 A (60.12 W) from a universal 90–264 VAC input, all in a fully sealed IP67 plastic enclosure. With no fan and free-air convection cooling, it runs silently and withstands dust, moisture, and temperature swings from -30°C to +70°C.

Key specifications

• Output: 36 VDC, 1.67 A, 60.12 W constant voltage
• Input: 90–264 VAC / 127–370 VDC, 47–63 Hz
• Efficiency: up to 90%
• IP67 waterproof and dustproof, plastic housing
• Protections: short circuit, overload, over voltage, over temperature
• Class II double insulation (no earth ground required)
• Operating temperature: -30°C to +70°C
• Safety: UL60950-1, TUV EN60950-1, EN61347-1, EN61347-2-13
• EMC: EN55032 Class B, EN61000-4-2,3,4,5,6,8,11

Why choose it

The OWA-60E-36 is built for permanent outdoor use. Its fully potted, IP67-rated plastic case prevents water and dust ingress, while the wide input range handles unstable mains or generator power. The fanless design eliminates moving parts, reducing maintenance and extending service life. Compliance with lighting and ITE safety standards makes it suitable for both LED drivers and general electronics.

Ideal use cases

• Outdoor LED lighting and signage
• Industrial sensors and controllers
• Automation equipment in wet or dusty areas
• Portable devices needing a rugged DC source

Good to know

The unit is free-standing and comes with 18 AWG input and output cables (UL 2464) for easy wiring. No additional enclosure or cooling is required. It is certified for Class II applications, meaning no protective earth connection is needed, simplifying installation in existing systems.
