MENNEKES 629A 16A 2P 25V IP44 gele industriestekker

For maintenance teams and machine operators working in low-voltage industrial environments, the MENNEKES 629A industrial plug provides a reliable connection for portable equipment. Its yellow housing follows the IEC 60309-2 colour code for 25 V systems, making voltage identification immediate.

Key specifications

• 16 A current rating
• 20-25 V voltage rating
• 2-pole (2P) configuration
• IP44 splash-proof protection
• Screw terminals for secure wiring
• Cable diameter 8-18 mm with strain relief
• Operating temperature -25 °C to +40 °C

Why choose it

The plug's polyamide housing and brass contacts withstand daily use, while the screw gland ensures a firm cable grip. Its IP44 rating guards against splashing water from any direction, making it suitable for damp locations.

Ideal use cases

• Connecting portable transformers or lighting in workshops
• Powering low-voltage tools on construction sites
• Temporary power distribution in industrial facilities

Good to know

The plug accepts conductors up to 2.5 mm² and is rated for 50/60 Hz operation. Its straight design allows easy insertion into compatible sockets.
