Metabo compressor MEGA 580-200 D 400V 200L 4kW 11bar 3-fase

The Metabo MEGA 580-200 D is a powerful 3-phase compressor delivering 580 l/min suction capacity and a 200 L tank, ideal for demanding workshop applications requiring high air volume.

Advantages

Belt-driven, oil-lubricated two-cylinder pump ensures durability and low wear. Two quick couplings (one regulated, one unregulated) provide flexibility for multiple tools. Integrated pressure reducer with filter and dual gauges for precise control.

Suitable for

• Workshops with high air demand
• Operating multiple pneumatic tools simultaneously
• Industrial and continuous use

Key specifications

• Power supply: 400 V, 3-phase
• Motor power: 4 kW
• Tank capacity: 200 L
• Suction capacity: 580 l/min
• Effective air delivery: 480 l/min at 80% max pressure, 400 l/min at 100% max pressure
• Max. operating pressure: 11 bar
• Number of cylinders: 2
• Pump speed: 1400 rpm
• Drive type: Belt-driven
• Pump type: Oil-lubricated piston compressor
• Sound power level: 97 dB(A)

Recommendations

For professional users needing reliable high-volume compressed air, this compressor offers robust performance and versatile connectivity.
