Bopla drukvereffenings-element M12x1,5 lichtgrijs IP68/IP69K 5-pack (52041009)

This Bopla pressure compensation element uses a PTFE membrane to equalize pressure in sealed enclosures while blocking water and dust, with an IP68/IP69K rating for demanding environments. The light grey polyamide body blends into most installations and resists UV and chemicals.

Highlights

• M12x1.5 thread for standard knockouts
• PTFE membrane with silicone seal
• Operating range -40 to +100 °C
• Air permeability approx. 1200 ml/min at 70 mbar
• Pack of 5 pieces

In daily use

Screw the element into the enclosure wall and tighten to 2 Nm using a 17 mm hex. The membrane equalizes internal and external pressure, preventing condensation and seal stress without letting moisture in. Suitable for outdoor and washdown applications.

Full specifications

• Product type: Pressure compensation element
• Thread size: M12x1.5
• Protection class: IP68, IP69K
• Colour: Light grey (RAL 7035)
• Body material: Polyamide (PA)
• Membrane material: PTFE
• Seal material: Silicone
• Operating temperature: -40 to +100 °C
• Air permeability: approx. 1200 ml/min at 70 mbar
• Mounting: Screw-in
• Recommended tightening torque: 2 Nm
• Hex nut size: 17 mm
• Thread length: 9 mm
• Overall height: 20 mm
• UV resistance: Yes
• Chemical resistance: Good
• Packaging quantity: 5 pieces

Final note

A reliable venting solution for enclosures exposed to temperature fluctuations and moisture.
