LC-glasvezelconnector BTR NETCOM 1509QAJO0010-E

The BTR NETCOM 1509QAJO0010-E LC fibre optic connector is designed for use with OS2 single-mode fibre. Supplied in a pack of 10 and finished in blue, this LC connector offers a compact form factor suitable for high-density patching panels and fibre optic cables. It is intended to provide consistent optical coupling and low insertion loss for installations that require stable single-mode connections.

Advantages

This LC connector is compatible with OS2 fibre and is produced to deliver reliable optical performance with low insertion loss. The compact LC form factor allows higher port density in racks and patch panels, while the blue color provides straightforward visual identification for single-mode links. Supplied in a 10-piece pack, it supports multiple terminations or spare inventory for network deployments.

Suitable for

• Single-mode OS2 fibre terminations in data centres
• Telecommunications backbone and access networks
• High-density patch panels and fibre distribution frames
• Field splicing enclosures and fibre assemblies

Key specifications

• Connector type: LC (Lucent Connector)
• Fibre compatibility: OS2 single-mode
• Color: blue (single-mode identification)
• Pack quantity: 10 pieces
• Typical use: indoor cabling, patching panels, fibre assemblies

How to use

Prepare the single-mode fibre by stripping, cleaving and cleaning according to standard fibre termination procedures. Insert the prepared fibre into the connector until it seats fully and secure following the connector assembly method applicable to the specific LC connector variant. After assembly, perform inspection and testing with an optical power meter or OTDR to verify low insertion loss and correct end-face condition. Follow site and safety procedures for handling optical fibres and connector tools.

Recommendations

Store connectors in a clean, dry environment and protect end faces with dust caps until installation. Use appropriate cleaning tools and inspection microscopes to ensure optimal performance. For critical links, verify connections after installation using insertion loss testing and document results for maintenance records.
