Microconnect FIB121003 InfiniBand/glasvezelkabel 3 m ST SC geel

Microconnect FIB121003 is a 3 m InfiniBand single-mode fibre optic cable with ST and SC connectors, designed for high-speed network links. Using OS2 fibre (9 µm core) in a yellow LSZH jacket, the cable supports Ethernet and InfiniBand connections over longer distances and conforms to common telecom standards.

Advantages

The OS2 single-mode construction provides low attenuation for long-distance data transmission; ST and SC connectors offer compatibility with a variety of transceivers and patch panels; LSZH jacket reduces smoke and toxic emissions in case of fire and meets common IEC and Telcordia requirements; 3 m length simplifies routing in data centres and server rooms while maintaining signal integrity for 1G/10G/40G/100G links and InfiniBand applications.

Suitable for

• Data centre and server farm interconnects
• Telecom rooms and patch panels
• Cloud storage networks and high-speed backbone links
• InfiniBand and Ethernet connections up to 100G

Key specifications

• Brand: MicroConnect
• Model / MPN: FIB121003
• Length: 3 m
• Connectors: ST to SC
• Fibre type: OS2 (single-mode)
• Core diameter: 9 µm
• Jacket: LSZH
• Colour: Yellow
• Typical reach: up to 10 km @ 1310 nm, up to 40 km @ 1550 nm
• EAN: 7331990015013

How to use

Inspect connectors and ports for dust or damage before installation. Align the ST connector and SC connector with the appropriate ports on your equipment or patch panels and insert until secure. Route the cable to avoid sharp bends and mechanical strain; maintain minimum bend radius recommended for single-mode fibre. For testing, verify continuity and signal levels with appropriate fibre test equipment after installation.

Recommendations

Use this OS2 ST–SC single-mode patch cord for long-reach links in enterprise networks, telecom rooms and data centres; store and handle connectors with protective caps when not connected to preserve performance.
