PEGASUS Thebai digitale tijdschakelaar, DIN-rail, 1 kanaal, 16A, LCD, 28 programma's

With a 16 A resistive switching capacity and 28 programmable ON/OFF cycles, the PEGASUS Thebai digital timer switch delivers precise automation for lighting, heating, and industrial control. Its DIN rail mounting and compact 1-module design make it a seamless fit in any distribution board.

Overview

The Thebai is a quartz-controlled digital timer switch engineered for reliable daily scheduling. It operates on 230 V AC and supports both resistive and inductive loads, handling up to 16 A and 10 A respectively. The clear LCD display and intuitive interface allow quick programming of up to 28 switching times, with a minimum interval of just one minute.

What stands out

• Manual override with permanent ON/OFF and temporary modes
• Automatic summer/winter time change for year-round accuracy
• Battery backup retains programs for approximately 3 years
• Changeover contact (SPDT) for flexible circuit control
• Wide operating temperature range from -20 °C to +55 °C

Technical details

• Supply voltage: 230 V AC, 50/60 Hz
• Switching capacity: 16 A resistive, 10 A inductive (cos φ = 0.6)
• Shortest switching time: 1 minute
• Program memory: 28 ON/OFF programs
• Power consumption: ~0.5 W
• Display: LCD
• Protection class: IP20
• Number of modules: 1 TE (18 mm)
• Contact type: Changeover (SPDT)
• Dimensions (W x H x D): 17.5 x 90 x 60 mm
• Weight: 0.1 kg

Our verdict

The PEGASUS Thebai combines robust switching performance with user-friendly programming, making it a dependable choice for both residential and commercial automation tasks.
