Pijpenbuigtang Gedore 2963515 voor buizen tot 22 mm

The Gedore tube bending tool 2963515 is designed for bending small-diameter tubes and pipes up to 22 mm. It performs controlled bends up to 180° and includes ten aluminium bending formers that fit a range of pipe diameters. The tool can be clamped in a vice for handheld use and, from a specified size, is compatible with a tripod for stationary operation. A pipe cutter accessory is provided and the complete set is supplied in a Gedore L-BOXX® case.

Advantages

The kit provides precision bending for steel, hydraulic and composite tubes while minimising kinking and deformation. Aluminium bending formers for multiple diameters are included to match common small pipe sizes. The tool offers both vice-mounted handheld use and, for larger sizes, the option to mount on a tripod for stationary work. A dedicated pipe cutter is included and the set is organised in a durable L-BOXX® case for transport and storage.

Suitable for

• Precision steel pipes (EN 10305-3 / DIN 2394)
• Hydraulic pipes (EN 10305-1 / DIN 2391) with wall thicknesses from 0.75 to 2.0 mm
• Composite pipes up to 16 mm outer diameter
• Bendable stainless steel pipes with 1.0–1.5 mm wall thickness
• Plumbing and HVAC small-diameter tube bending tasks

Key specifications

• Bend range: up to 180°
• Supported pipe diameters: 3–10 mm with included formers; formers supplied for Ø 3–4, 5, 6, 8, 10, 12, 14, 15, 16 and 18 mm
• Maximum compatible pipe outer diameter stated by manufacturer: up to 22 mm
• Wall thickness compatibility: 0.75–2.0 mm for hydraulic pipes, 1.0–1.5 mm for bendable stainless steel
• Includes 10 aluminium bending formers
• Clamping method: vice-mounted for handheld use; compatible with tripod for stationary use (tripod sold separately)
• Includes pipe cutter accessory
• Case dimensions: W 442 × D 357 × H 151 mm; delivered in Gedore L-BOXX® 136

How to use

Select the aluminium bending former that matches the pipe outer diameter, secure the tool in a vice if performing handheld bending or mount it on a compatible tripod for stationary bending where applicable. Insert the pipe into the selected former and perform the bend slowly to the required angle, up to 180°, ensuring even pressure to avoid kinks. Use the included pipe cutter to prepare pipe ends to the correct length and to obtain clean, square cuts before bending.

Recommendations

Use the formers that closely match the pipe diameter and follow the wall thickness limits specified by the manufacturer. For pipes larger than 10 mm consider mounting the tool on a tripod for improved stability. Inspect pipes for damage and remove burrs after cutting to ensure precise, clean bends.
