Prodipe B210DUO DSP UHF dual draadloos microfoonsysteem

Live sound engineers and performers often struggle with wireless microphone systems that suffer from interference, dropouts, and limited control over their audio. The Prodipe B210DUO DSP UHF solves these issues by delivering a robust dual-channel UHF wireless system with true diversity reception and integrated digital signal processing, ensuring clean, reliable audio in any venue.

Who is it for

This system is ideal for musicians, presenters, houses of worship, and event production teams who need a dependable dual wireless microphone setup without the complexity or cost of high-end professional systems. It suits both fixed installations and mobile rigs.

Main features

• Dual-channel UHF wireless receiver with true diversity for dropout-free performance
• 200 selectable frequencies (2 x 100) across 630-680 MHz for flexible coordination
• Integrated DSP with EQ, anti-feedback, and compressor for polished sound
• Infrared synchronization instantly links transmitters to the receiver
• Clear LCD display on receiver for monitoring RF and audio levels
• Two balanced XLR outputs and one 6.35mm jack for versatile connectivity
• Handheld dynamic cardioid microphones with up to 10 hours battery life

Specifications

• System Type: Dual UHF Wireless Microphone System
• Frequency Band: UHF 630-680 MHz
• Number of Channels: 2 (Dual Channel)
• Selectable Frequencies: 2 x 100 (200 total)
• Receiver Type: True Diversity
• Microphone Type: Dynamic Handheld
• Microphone Polar Pattern: Cardioid
• Frequency Response: 50 Hz - 18 kHz
• Dynamic Range: > 100 dB
• Total Harmonic Distortion (THD): < 0.5%
• Signal-to-Noise Ratio (SNR): > 96 dB
• Operating Range: Up to 100 meters (line of sight)
• Receiver Outputs: 2 x XLR Balanced, 1 x 6.35mm Jack Unbalanced
• Transmitter RF Power: 10 mW
• Transmitter Battery Type: 2 x AA (per microphone)
• Transmitter Battery Life: Approx. 8-10 hours
• DSP Features: Integrated Digital Signal Processing (EQ, Anti-Feedback, Compressor)
• Synchronization: Infrared (IR) Sync
• Receiver Display: LCD

Tips

For best results, keep the receiver antennas fully extended and positioned vertically. When using multiple systems, ensure each operates on a different frequency group to avoid intermodulation. Replace transmitter batteries before each performance to maintain consistent RF output.
