RUBI Diamantschijf voor harde materialen, Turbo Edge VIPE 300 mm

The RUBI Diamond Blade for Hard Materials, Turbo Edge VIPE is a high-performance cutting tool designed for demanding applications on hard materials such as granite, porcelain stoneware, clinker, rustic stoneware, refractory, facing brick, and slate. With a 300 mm diameter and 25.4 mm bore, this sintered diamond blade features a turbo segmented edge for fast, clean cuts. It is recommended for wet cutting and is compatible with electric tile cutters and masonry saws. The blade meets EN 13236 standards and is built with a high-quality steel core for durability and precision.

Advantages

This blade offers high cutting speed and a clean finish, reducing the need for additional finishing work. The turbo edge design enhances cooling and debris removal, extending blade life. Its sintered bond provides excellent wear resistance, making it ideal for continuous professional use.

Suitable for

• Granite
• Porcelain stoneware
• Clinker
• Rustic stoneware
• Refractory materials
• Facing brick
• Slate

Key specifications

• Blade Diameter: 300 mm
• Bore Diameter: 25.4 mm (1 inch)
• Blade Type: Diamond Cutting Blade
• Edge Type: Turbo Segmented
• Segment Height: 8 mm
• Segment Thickness (Kerf): 2.6 mm
• Max Rotational Speed: 5100 RPM
• Bond Type: Sintered
• Product Series: VIPER
• Standard Compliance: EN 13236
• Core Material: High-Quality Steel
• Cutting Method: Wet Cutting (Recommended)

Recommendations

For optimal performance and safety, always use this blade with water cooling and follow the manufacturer's guidelines. Ensure the blade is properly mounted and the maximum rotational speed is not exceeded. Suitable for use with electric tile cutters and masonry saws.
