RUKO MGR-DIN357-M10x1,5mm RVS A2 beugelklem, 100mm breed, 150mm hoog, met moeren en sluitringen

Secure pipes and tubes in marine and industrial environments with this RUKO U-bolt. Made from stainless steel A2 (AISI 304), it offers high corrosion resistance for outdoor use. The M10 coarse thread with 1.5 mm pitch ensures a strong hold when fastening to structural supports.

Key specifications

• Standard: DIN 357
• Material: Stainless Steel A2 (AISI 304)
• Thread: M10 x 1.5 mm metric coarse
• Internal width: 100 mm
• Internal height: 150 mm
• Leg length: 170 mm
• Included: 2 hexagon nuts (DIN 934) and 2 flat washers (DIN 125)

Why choose it

The A2-70 tensile strength class and bright polished finish provide reliable performance and a clean appearance. The stainless steel construction withstands temperatures from -50°C to +400°C and resists many chemicals, though it is not suitable for highly acidic or chloride-rich environments.

Ideal use cases

• Pipe and tube fastening
• Structural mounting
• Marine applications
• Industrial installations

Good to know

This U-bolt is supplied with matching nuts and washers for immediate installation. Its dimensions make it suitable for clamping components with an outer diameter up to 100 mm.
