SCHNEIDER ELECTRIC 2S/16A/IP21 Q-CONN WIT

Double pole switch with quick-connect terminals, rated 16 A at 250 V AC, in a robust white thermoplastic housing. This surface-mounted switch provides reliable ON/OFF control for residential, commercial, and light industrial circuits, with screwless wiring for fast installation.

Advantages

The Q-Conn series combines safety and convenience: IP21 protection guards against solid objects over 12.5 mm and vertical water drops, while the double pole design isolates both live and neutral for enhanced safety. Quick-connect terminals accept rigid or flexible conductors up to 2 x 2.5 mm², reducing wiring time and ensuring secure connections without screws. The thermoplastic material offers high impact resistance and long-term durability, with a mechanical life of 20,000 cycles.

Suitable for

• Residential lighting and appliance circuits
• Commercial switchboards and control panels
• Light industrial equipment isolation
• Surface-mounted installations in dry or protected environments

Key specifications

• Switch type: Double pole
• Current rating: 16 A
• Voltage rating: 250 V AC
• Ingress protection: IP21
• Connection: Quick connection terminals (screwless)
• Mounting: Surface mounted
• Colour: White
• Material: Thermoplastic
• Standards: IEC 60669-1
• Operating temperature: -5°C to +40°C
• Terminal capacity: Up to 2 x 2.5 mm²
• Mechanical durability: 20,000 cycles

Recommendations

For electricians and installers seeking a dependable, easy-to-wire double pole switch, the Schneider Electric WDE002596 delivers consistent performance and compliance with international standards. Pair with matching white surface boxes for a clean finish.
