SCHROFF 19 inch moduledrager 84HP 115T 3U frontplaat 24563-100

The SCHROFF 24563-100 is a 3U front panel for 19-inch rack systems, offering a robust blanking solution that protects internal components while maintaining a clean, professional appearance. Constructed from anodized aluminum, it provides excellent corrosion resistance and durability for demanding environments.

Advantages

This front panel is precision-engineered to IEC 60297-3-101 standards, ensuring perfect compatibility with standard 19-inch subracks. Its 84HP width and 115 mm depth compatibility make it versatile for various subrack configurations. The anodized natural silver finish not only enhances aesthetics but also adds a layer of protection against wear and corrosion.

Suitable for

• Blanking unused slots in 19-inch subracks
• Protecting internal electronics from dust and accidental contact
• Maintaining proper airflow and thermal management
• Creating a uniform front appearance in server rooms and industrial cabinets

Key specifications

• Rack unit height: 3U
• Horizontal pitch width: 84HP (84 TE)
• Material: Aluminum, anodized
• Colour: Natural silver
• Panel thickness: 2.5 mm
• Dimensions: 128.4 mm height x 426.7 mm width
• Mounting holes: Pre-drilled
• Standard compliance: IEC 60297-3-101

Recommendations

For optimal performance, pair this front panel with SCHROFF subracks and accessories. Ensure proper alignment during installation to maintain the structural integrity of the rack system. Regular inspection of the anodized surface will help preserve its appearance and protective qualities.
