Seriële kabel HP HPE 316131-001 voor StorageWorks Modular SAN Array 1000

Serial cable HP HPE 316131-001 for StorageWorks Modular SAN Array 1000 is a dedicated OEM console/management cable designed to provide a reliable physical connection between management stations and the SAN array. It ensures stable transmission of serial data and control signals for configuration, monitoring and troubleshooting of the StorageWorks Modular SAN Array 1000 hardware.

Advantages

This HP serial cable offers compatibility with the StorageWorks Modular SAN Array 1000, providing a direct and dependable link for console access and hardware management. The cable is manufactured to OEM specifications to ensure signal integrity, mechanical fit and ease of installation. Using a purpose-made cable reduces the risk of connection issues during critical maintenance and diagnostic operations.

Suitable for

• Console access and CLI configuration of StorageWorks Modular SAN Array 1000
• On-site hardware diagnostics and troubleshooting
• Firmware updates and device management via serial connection
• Replacing lost or worn OEM management cables

Key specifications

• Function: Serial console/management connectivity for SAN array
• Compatibility: Designed for StorageWorks Modular SAN Array 1000
• Cable type: Serial interface cable for console port use
• Signal support: Bi-directional serial data and control signals
• Construction: OEM-grade connectors and shielding for reliable connection

How to use

Connect the cable between the SAN array console port and the corresponding serial or adapter port on a management workstation or terminal server. Launch the terminal emulator on the workstation with the appropriate serial settings required by the StorageWorks Modular SAN Array 1000 (baud rate, parity, data bits, stop bits) and establish the session to access CLI functions. Use the connection for configuration changes, monitoring, firmware uploads and troubleshooting as required.

Recommendations

Store the cable coiled without tight bends and avoid sharp kinks. Inspect connectors for damage before use and ensure firm seating to avoid intermittent connections. Use a compatible serial adapter or converter if the management workstation lacks a native serial port, and confirm terminal settings match the SAN array documentation before making configuration changes.
