SFP-transceivermodule BlueOptics RDH10270/2-I-40-BO 1000 Mbit/s 1270 nm

The BlueOptics RDH10270/2-I-40-BO SFP transceiver module is a compact fiber optic interface designed for gigabit networks. It supports a maximum data transfer rate of 1000 Mbit/s and transmits at a wavelength of 1270 nm via an LC connector. With an SFP form factor and a lightweight metal housing, this module is intended for use in switches, routers and media converters where a reliable single-fiber optical link is required. The module is specified with an expected MTBF of 3,000,000 hours and a maximum optical reach of up to 40,000 m under appropriate conditions.

Advantages

The RDH10270/2-I-40-BO offers stable optical transmission in a compact SFP package and is compatible with standard MSA form-factor ports. Its LC fiber connector and single-fiber design simplify cabling and enable duplex communication over a single strand when matched with a complementary transceiver. The module's silver metal housing and low weight make it easy to install and integrate into existing network hardware. An MTBF rating of 3,000,000 hours indicates long operational life and reduced maintenance frequency.

Suitable for

Key specifications

How to use

Install the transceiver into a compatible SFP slot of a switch, router or media converter, ensuring the module is oriented correctly and fully seated until it locks. Connect an LC fiber patch cable between this transceiver and the matching transceiver or patch panel. Verify that the remote device uses the complementary wavelength and that both ends support the intended single-fiber configuration. After physical installation, check link status indicators on the networking equipment and configure the port settings (speed/duplex) as required by your network environment.

Recommendations

For optimal performance, use singlemode fiber of appropriate grade and LC patch cables, keep connectors clean and properly aligned, and ensure the remote transceiver supports the matching wavelength pairing. Monitor link health via the host device; if available, enable Digital Diagnostics Monitoring (DDM/DOM) on supported hardware to track optical power and temperature parameters.
