Siemens PROFIBUS-stekker 90° haaks tot 12 Mbit/s 6ES7972-0BA12-0XA0

The Siemens 6ES7972-0BA12-0XA0 is a high-performance PROFIBUS DP connector designed for industrial automation and fieldbus communication. Featuring a 90-degree angled cable outlet, this FastConnect (FC) connector ensures easy installation in tight spaces. It supports data transfer rates up to 12 Mbit/s and includes an integrated switchable termination resistor for reliable bus termination. The robust metalized plastic housing provides excellent EMC immunity, making it suitable for demanding industrial environments.

Advantages

This connector offers quick and tool-free wiring with Siemens FastConnect technology, reducing installation time. The 90-degree outlet allows for space-saving cable routing, and the integrated PG socket enables easy connection of programming devices. The switchable termination resistor simplifies network configuration.

Suitable for

• Industrial automation systems using PROFIBUS DP networks
• Fieldbus communication in manufacturing and process industries
• Applications requiring reliable data transmission up to 12 Mbit/s
• Installations where space is limited and angled cable outlet is needed

Key specifications

• Product Type: PROFIBUS Connector
• Bus System: PROFIBUS DP
• Data Transfer Rate: Up to 12 Mbit/s
• Cable Outlet Direction: 90 degrees (angled)
• Connection Technology: FastConnect (FC)
• Integrated Termination Resistor: Yes, switchable
• PG Socket: Yes
• Number of Pins: 9-pin D-sub (DB9)
• Shielding: Integrated metal housing for high EMC immunity
• Operating Voltage: 5 V DC (via PROFIBUS)
• Current Consumption: Max. 10 mA
• Cable Type Compatibility: PROFIBUS FC standard cable
• Housing Material: Metalized plastic
• Degree of Protection: IP20
• Operating Temperature: -25 to +60 °C
• Storage Temperature: -40 to +70 °C
• Relative Humidity: 95% (non-condensing)
• Mounting Type: Direct plug-in

Recommendations

For optimal performance, use with Siemens PROFIBUS FC standard cables and ensure proper termination. This connector is ideal for new installations or retrofitting existing PROFIBUS networks.
