Sonnet Echo 13 Thunderbolt 5 SSD-dock bedraad zwart 140W Power Delivery

Sonnet Echo 13 Thunderbolt 5 SSD Dock is a wired docking station that combines high-performance internal NVMe storage with Thunderbolt 5 connectivity and multi‑port expansion. It is compatible with Mac (including Apple M series), Windows, Chromebook and iPad Pro systems and offers a single-cable workflow with up to 140W USB Power Delivery to charge a connected laptop. The dock includes pre-installed Kingston M.2 NVMe SSD options (1TB, 2TB, or 4TB) and supports high-speed data transfers and multiple external displays.

Advantages

The Echo 13 delivers up to 6000 MB/s transfer speed when connected to a Thunderbolt 5 host (up to 3400 MB/s on Thunderbolt 4 or 3 hosts) via its built-in Kingston PCIe 4.0 NVMe SSD. Four Thunderbolt 5 ports, three 10Gbps USB-A ports, 2.5Gb Ethernet, SD and microSD card slots, and 8K display support provide broad connectivity. The dock supplies up to 140W power delivery to charge a laptop and offers bus-power-friendly USB-A ports that provide up to 7.5W each for connected peripherals.

Suitable for

Key specifications

How to use

Connect the included Thunderbolt 5 cable between the Echo 13 dock and your Thunderbolt‑capable computer to enable data, video, network, and power delivery over a single cable. Plug monitors, USB peripherals, and an Ethernet cable into the dock’s rear ports and insert SD/microSD cards as needed. Use the front Thunderbolt 5 port or USB‑A ports for bus‑powered devices and charge mobile devices from the front ports even when the host computer is asleep or turned off.

Recommendations

For maximum internal SSD performance (up to 6000 MB/s) use the Echo 13 with a Thunderbolt 5 host. When connecting to a network switch or NAS, use Cat5e or better cabling to achieve 2.5Gb/s Ethernet performance. Consult your computer’s specifications for multi‑display support; adapters may be required for HDMI or DisplayPort monitors.
