SYNERGY21 LED Flex Strip 2835 - 120 WW Pixel DC24V WS2811 IP20

The SYNERGY21 LED Flex Strip 2835 is a high-quality, individually addressable LED strip designed for professional indoor lighting applications. Featuring 120 SMD 2835 LEDs per meter with warm white output (2700K-3000K), this strip is powered by DC 24V and controlled via the WS2811 IC, allowing each pixel (3 LEDs) to be addressed independently. With a beam angle of 120°, IP20 rating, and 3M self-adhesive backing, it is ideal for decorative, accent, and architectural lighting.

Advantages

Individually addressable pixels enable dynamic lighting effects and animations. High LED density ensures smooth, uniform illumination. The 24V DC operation reduces voltage drop over longer runs. Easy installation with cuttable segments every 3 LEDs and pre-attached 3-pin JST SM connector.

Suitable for

• Indoor decorative lighting
• Architectural accent lighting
• Signage and channel letters
• Stage and event lighting
• DIY projects and custom installations

Key specifications

• LED Type: SMD 2835
• LED Density: 120 LEDs/meter
• Color: Warm White (2700K-3000K)
• Control IC: WS2811 (1 IC controls 3 LEDs)
• Input Voltage: DC 24V
• Power Consumption: Approx. 12W/meter
• Beam Angle: 120°
• IP Rating: IP20 (Indoor use only)
• Cuttable: Every 3 LEDs (~2.5 cm)
• Adhesive: 3M self-adhesive backing
• Operating Temperature: -20°C to +50°C
• Lifespan: >50,000 hours
• Dimmable: Yes (via compatible controller)
• CRI: >80 Ra
• Pixels: 40 pixels/meter
• PCB Width: 10 mm
• Connectivity: 3-pin JST SM connector (Data, VCC, GND)
• Certifications: CE, RoHS

Recommendations

For optimal performance, use a compatible 24V LED controller and power supply. Ensure proper ventilation and avoid exposure to moisture. Suitable for indoor use only.
